Overview

• Monitor your pedaling cadence as you ride with this easy-to-install wireless sensor.
• The Bike Cadence Sensor 2 fastens to any size crank arm and measures pedal strokes per minute so you can get the most out of your training.
• Send live cadence data to compatible training apps or displays using ANT+ connectivity.
• View Garmin user manuals for:
• GSC 10 (PDF)
• Bike Speed + Cadence Sensors (PDF)
• Bike Speed + Cadence Sensors 2 (WEB/PDF)





Bike Cadence Sensor Specifications

Getting Started

• While the Bike Cadence Sensor is ready to use right out of the box, we do recommend checking and/or replacing the CR2032 battery installed during production before mounting to your bicycle.
• The sensor will now be ready to connect with your compatible GPSr.
• The Bike Cadence Sensor can be paired with multiple ANT+ devices.

Pair GPSr and Cadence Sensor

• Bring GPSr and Bike Cadence Sensor within 3m (10 ft) of each other
• Ensure no additional wireless sensors are located within this 3m (10 ft) range
• Rotate crankshaft (without turning wheels) 2 full revolutions to wake the Bike Cadence Sensor (green LED flashes for 5 seconds)
• If the LED flashes red, the battery charge level is low and requires replacement.
• If the LED does not flash, check battery installation for correct polarity and replace as needed
• Select [Setup] > [Sensors] or [ANT Sensor] > [Bike Cadence Sensor] > [Search For New]
• GPSr will report 'Searching...'
• If a Bike Cadence Sensor 2 is located, your device may allow you to choose either an ANT+ or Bluetooth connection:
  • ANT+ - Allows unlimited device connections.
  • Bluetooth - Only a limited number of device connections are allowed (usually 2).
• The GPSr will report 'Connected' once the Bike Cadence Sensor is paired.
• It may be helpful to continue rotating the crankshaft during this initial setup procedure

Enable Bike Cadence Sensor

• Select [Setup] > [Sensors] or [ANT Sensor] > [Bike Cadence Sensor] > [On]
• GPSr will report 'Searching...' then 'Connected' once a Bike Cadence Sensor is located
• The GPSr may not display 'Connected' until the Bike Cadence Sensor starts transmitting data

Disable Bike Cadence Sensor

• Select [Setup] > [Sensors] or [ANT Sensor] > [Bike Cadence Sensor] > [Off]
• GPSr will report the Bike Cadence Sensor as 'Disabled'

View Bike Cadence Sensor Data on GPSr

• Cadence data can be viewed on your GPSr in multiple Data Fields
• Data Field availability may vary from one device to another

BaseCamp and Bike Cadence Sensor Data

• With a Cadence sensor connected, your track log recording will include cadence data with each track point saved.
• Saved Track Logs can be imported into BaseCamp for analysis.



Cadence Sensor Battery Replacement
